BFT Deimos BT Slide Gate Kit A600 Fra 230V - R925271 00002
Details
BFT Deimos BT Slide Gate Kit A600 Fra 230V - R925271 00002
The BFT Deimos BT Slide Gate Kit A600 FRA is a complete system for heavier sliding gates up to 600 kg. The package includes the Deimos BT A600 operator with D-Track torque management, a RADIUS B LTA 24 R1 flashing light with integrated antenna, DESME A15 self-aligning photocells, and a MITTO B RCB04 R1 four-channel transmitter. This combination ensures smooth, secure, and efficient gate movement in changing environmental conditions. It is an ideal solution for demanding residential and commercial installations.
Features
- Complete automation kit for gates up to 600 kg
- D-Track torque management for adaptive control
- Flashing light with built-in antenna
- Self-aligning photocells with 30 m range
- Four-channel transmitter included
Specifications
- Model: Deimos BT Slide Gate Kit A600 FRA
- Power Supply: 230V
- Motor Voltage: 24V
- Leaf Speed: 12 m/min
- Limit Switch: Electromechanical
- Locking: Mechanical
- Technology: D-Track
BFT Slide Gate Model Comparison Chart:
| Ares Series | Deimos Series | Icaro Series | Rack & Pinion Series | |
| Gate Capacity | 500 kg - 1,650 kg (1,100 - 3,300 lbs) | 400 kg - 1,100 lbs | 1,000 kg - 2,200 kg (2,200 - 4,400 lbs) | Up to 7,000 lbs |
| Motor Voltage | 24V, 120V, 230V | 24V, 120V, 230V | 120V, 230V | 230V (three-phase) |
| Speed | 5.9 - 39 ft/min | 7.9 - 12 m/min | 7.9 - 22 m/min | 34.5 ft/min |
| Duty Cycle | Intensive use | Semi-intensive to intensive use | Very intensive use | Very intensive use |
| Special Features | D-Track torque management, programmable slowdown, mechanical locking | D-Track torque management, obstruction sensing, LCD control board | D-Track torque management, mechanical clutch, oil bath gearbox, U-Link connectivity | Hydrodynamic gear system, electromechanical limit switches, electric brake |
| SKU | R925271-00002 |
|---|---|
| Alternate Part Number | 2611825 |
| Opening Speed | 7.9" per second |
| Input Voltage | 220/230/240 AC (60 Hz, 1 Phase), 230 AC (50 Hz, 1 Phase) |
| Max Gate Weight | 1320 lbs |
| Max Gate Length | 75 ft |
| Slide Gate Model | Deimos |
| Brochure | Download PDF file |
| Catalog | Download PDF file |
| Cut Sheet | Download PDF file |
| Manual | Download PDF file |
| Quick Start Guide | Download PDF file |
