BFT LUX FC-2B 230V Hydraulic Swing Gate Opener - P935039 00001
Details
BFT LUX FC-2B 230V Hydraulic Swing Gate Opener - P935039 00001
The LUX FC 2B hydraulic gate opener operates swing gates up to 2m long and 300kg in weight. Cycle time 17sec. Power input 280W.
- Control Unit: Alcor N, Rigel 5
- Motor Power Supply: 230
- Slowdown: No
- Impact Reaction: Hydraulic Clutch
- Frequency of Use: Very Intensive
- Environmental Conditions (min): -10
- Environmental Conditions (max): 60
- Protection Rating: IP57
| SKU | P935039-00001 |
|---|---|
| Manual | Download PDF file |
| Specification Sheet | Download PDF file |
Input Voltage
Need to know the difference between voltages? Check out our guide!
Learn More
|
220/230/240 AC (60 Hz, 1 Phase), 230 AC (50 Hz, 1 Phase) |
| Swing Gate Model | Lux |
| Operator Type | Actuator Arm |
| Max Gate Length | 10 ft |
| Max Gate Weight | 660 lbs |
| Opening or Closing Time | 17 seconds |
|
Warranty
Browse Our Warranty Info for More Details
Read Now
|
24 Months |
