BFT Phobos BT Kit A40 Fra 230V - R935309 00005

Details

BFT Phobos BT Kit A40 Fra 230V - R935309 00005

This complete kit includes the Phobos BT A40 operator, which ensures precise movement through its magnetic limit switch system, allowing for quick and easy adjustments. The system operates on 24V technology, providing optimal performance with precise slowdown adjustments during opening and closing, and ensures immediate stopping and reversal upon detecting obstacles. The included ZARA BT L2 control panel features dip switches and potentiometers for straightforward programming of one or two 24V operators for swing gates. Additionally, the kit comprises a pair of DESME A15 self-aligning photocells with a range of 30 meters, enhancing safety by detecting obstructions in the gate's path.

Specifications

• Power Supply: 230V
• Motor Voltage: 24V
• Maximum Gate Weight: 500 kg
• Maximum Gate Length: 4 meters
• Useful Rod Stroke: 400 mm
• Maximum Opening Angle: 124 Degrees
• Control Unit: ZARA BT L2
• Limit Switch Type: Magnetic
• Slowdown: Yes
• Locking: Mechanical
• Release: Personal Key
• Impact Reaction: D-Track
• Frequency of Use: Intensive
• Protection Rating: IPX4
• Operating Temperature: -20 to 55 Degrees Celsius
• Operation Time (90 Degrees, excluding slowdown, with maximum gate size and weight): approximately 20 seconds
